99.6%
Clean cut rate
No tail or whisker
±0.5mm
Cut placement accuracy
At full line speed
12+
Film types supported
PE, OPP, laminate, compostable
< 90 sec
Blade changeover
Tool-free quick-release
One jaw stroke. Perfect seal and cut.
Four engineering decisions that eliminate tailing, whiskers, and seal quality variation.
2
Cut method options
Heated Wire & Rotary Blade Options
Choose from a heated wire cutter for clean thermal separation on standard PE film, or a servo-driven rotary blade for precision mechanical cutting on laminated and compostable films. Both mount to the same jaw assembly.
0
Tail & whisker defects
Integrated Seal-and-Cut Jaw
The seal and cut functions share a single jaw stroke — the film is sealed and severed in one motion with no re-index. This eliminates the timing offset that causes tailing and whisker formation on standard two-step systems.
Auto
Film profile selection
Auto Film-Type Detection
An onboard film sensor identifies film type and thickness at startup and auto-selects the correct temperature and pressure profile. Operators switching between PE and compostable film no longer need to manually re-enter parameters.
< 90s
Blade changeover time
Tool-Free Blade Swap
Quick-release blade cartridges change in under 90 seconds without tools. Blade life tracking on the HMI triggers a change alert before quality is affected — no more reactive blade changes after defects appear on line.
Equipment this upgrade works on.
LeMatic Horizontal Baggers
LX-120 / LX-350 / LX-470
- Direct jaw-mount integration
- HMI film profile sync
- Blade life tracking
- No adapter required
Line Compatibility
Drops into your existing cross-seal station.
12+
Film types supported
<2hr
Typical install window
Machine Compatibility
Works with the bagger you already own.
Compliance & Certification
