400mm
Max seal width
Single pass
99.3%
Hermetic seal rate
Across all film weights
0–30m
Line speed range
Adjustable via HMI
< 5 min
Belt changeover
No tools required
Continuous sealing. Hermetic results.
Four engineering decisions that eliminate seal quality variation and unplanned downtime.
30m/min
Max throughput speed
Continuous Band Sealing
Two Teflon-coated stainless steel bands run continuously at line speed — there is no dwell cycle, no stop-start motion. Bags feed through the nip point at up to 30m/min and emerge with a structurally sealed closure every time.
2-zone
Heat + cool control
Dual-Zone Temperature Control
A heating zone and an immediately downstream cooling zone are independently controlled. The seal is formed in the heat zone and set rigid in the cooling zone before the bag leaves the machine — no post-seal handling damage.
60 sec
Film weight changeover
Adjustable Nip Pressure
Pneumatic nip roller pressure is set per film weight and adjusted from the HMI without reaching into the machine. Operators switching between lightweight PE and heavier laminated film recall a saved pressure profile in under 60 seconds.
< 5 min
Belt replacement time
Tool-Free Belt Replacement
Sealing belts are tensioned on quick-release spools — no wrenches, no alignment fixtures. Belt wear is tracked on the HMI and a replacement alert triggers before seal quality degrades, keeping maintenance predictable and planned.
Equipment this upgrade works on.
LeMatic End-of-Line Baggers
LX-350 / LX-470 bagging systems
- Inline conveyor integration
- HMI speed synchronization
- Belt wear tracking
- No adapter required
Line Compatibility
Inline or stand-alone — your choice.
30m
Max line speed per minute
<2hr
Typical install window
Machine Compatibility
Works with your existing packaging line.
Compliance & Certification
